Long Range Wireless Wifi Router 2.4G 5.8G 1200mbps 4 Lan Ports With 4G Module

Brand Name : ZBT

Model Number : ZBT-WG3526

Certification : CE,FCC,roHs

Place of Origin : China

MOQ : 1pcs

Price : Negotiation

Payment Terms : T/T, Western Union, MoneyGram and PayPal

Supply Ability : 1000pcs/Month

Delivery Time : 5-8 working days for sample order

Packaging Details : 10pcs/CTN, Carton size:482*320*350mm,15kg/Carton

Product Name : Long Range 2.4G&5.8G 1200mbps 3/4G Wi-Fi Router With 4G Module

RAM : DDR3 RAM 512MB (MAX512MB)

FLASH : SPI FLASH 16MB (MAX32MB)

Protocol Standard : IEEE802.11ac/n/g/b/a

Rate : 1200Mbps

Lan ports : 4

Warrenty : 1 Year

Contact Now

Long Range 2.4G&5.8G 1200mbps 3/4G Wi-Fi Router With 4G Module

Latest Dual core network chipset MT7621,Clock Frequency get 880Mhz
Provide 5 gigabit Auto MDI/MDIX Ethernet port
1 USB 3.0 port
Provide 1 Micro SD Card slot+1 mini PCIE slot+1 SIM card slot
support IEEE IEEE802.11AC/N/G/B/A wireless protocol
The transmission rate get to 1200Mbps

Hardware

ZBT-WG3526 uses the latest MTK wireless solution, the MT7621, the clock frequency is as high as 880MHZ, provide 5 gigabit Auto MDI/MDIX Ethernet port, 1×USB 3.0 port ,1×Micro SD card

Wireless

Support IEEE802.11ac/n/g/b/a wireless protocol, max wireless rate could be 1200Mbps , 4×5Dbi high gain antennas , perform better and cover larger.

Hardware Specification
Main Chipset	MT7621/Dual Core/880Mhz
RAM	DDR3 RAM 512MB (MAX512MB)
FLASH	SPI FLASH 16MB (MAX32MB)
Protocol Standard	IEEE 802.11ac,IEEE 802.11a IEEE 802.11n,IEEE 802.11g,IEEE 802.11b； IEEE 802.3,IEEE 802.3u；
Wireless Rate	5G : 900Mbps 2.4G: 300Mbps
Work Frequency	2.4GHz/5.8GHz
Antenna	4 * 5dBi high gain antenna or 6 external antenna (Adding 3G or 4G module)
Interface	110/100M/1000M WAN Port, Auto MDI/MDIX 410/100M/1000M LAN Port, Auto MDI/MDIX 1USB 3.0 port 1Mini-PCIE slot 1 SIM card slot
LED	PWR.SYS.USB.2G.5G.WAN, LAN1-4
Button	1*RESET
Power consumption	< 24W
Adapter	DC 12V 2A
Others
Work Environments	Operating Temperature:-10℃ ~ 60℃； Storage Temperature:-40℃~ 70℃； Operating Humidity:10%~90% non-condensing Storage Humidity:10%~90% non-condensing
Authentication	FCC, CE, ROHS
